X=0: real-time tracking mode: the device is always online, the default 30s+50 meters relative mileage returns a piece of data, there is inflection point supplementary data and blind zone supplementary data, and the track is complete. Drive 2 hours a day, return transmission interval 30S, theoretical standby 15 days.
X=1: Deep power saving mode (10 means the set time interval (range: 10-720 minutes): Deep power saving mode: wake up according to the set return time interval. The return interval ranges from 10 to 720 minutes. During this period, the vibration cannot be awakened, and the light sensor can wake up. The theory is one and a half to two years.
When the device enters the static state, it will go offline. After the vibration wakes up, it will go online (that is, online when driving, offline when not driving, saving power than real-time tracking mode). The default 30s + 50 meters relative mileage returns a piece of data, there is an inflection point to pass data and a blind area to pass data, and the track is complete. Β Drive 2 hours a day, return transmission interval 30S, theoretical standby 15 days.
| Product Code | SW-GTS15 |
| Type: | Real-Time GPS Tracking |
| Positioning Accuracy: | Β 10meters, 2D RMS |
| Input voltage: | DC 9V~36V/1.5A |
| Back-up Battery: | 10000mAh/3.7V |
| GPS Sensitivity: | -158dB |
| Velocity Accuracy: | 0.1m/s |
| GSM Frequency: | GSM 850/900/1800/1900MHz |
| GPRS: | Class12, TCP/IP |
| Working Voltage: | 3.90V DC |
| Working current: | β35mA (12vDC) |
| Working current: | β4mA (24vDC) |
| GPS Precision: | 10m(2D RM) |
| Working temperature: | -20β~+70β |
| Working humidity: | 20%~80%RH |
| Microphone: | Default |
| Velocity: | 515 meters/second (1000 knots) max |
| Channels: | 20-channel all-in-view tracking |
| Application: | Real-time tracking/Voice monitoring |
| Product Dimension: | L86*W62*H30MM |
| Net Weight: | Β 255 g |
